An insulator is a substance that partly blocks or slows the flow of heat through it. Styrofoam is a lightweight plastic used in drinking cups. Styrofoam is a good insulator. A cooler or ice chest that is made of Styrofoam or some other insulator tends to block the flow of heat through it.

Heat flows into buildings during warm summer months and from buildings during cold winter months. Energy must be used to cool buildings in the summer and heat them in the winter. Since insulation can slow the flow of heat, the use of insulation in buildings can save energy.

Some common home and building insulation materials include Styrofoam, polyurethane foam, and fiberglass. These materials are all good insulators, which means that they are poor conductors of heat. Placing these insulating materials on attic floors or in building walls tends to trap heat inside during the cold winter and keep heat out during the hot summer.

Plastic foams filled with trapped gas tend to block heat flow. The chemicals used to make polyurethane foam can be sprayed directly into the spaces between walls. These chemicals produce carbon dioxide gas and polyurethane plastic. The gas tends to spread the polymer apart so the weight is mostly plastic but the volume is mostly trapped gas. Polyurethane also is used to insulate refrigerators, refrigerated trucks, pipes, and building walls.

Fiberglass insulation is frequently used in attic floors to insulate homes. Also, fiberglass insulation is used to insulate the Trans-Alaska pipeline. This pipe carries oil 800 miles from Prudhoe Bay in northern Alaska to Valdez in southern Alaska. The crude oil that travels through this pipe is easier to pump if it is hot. An insulated pipeline requires less energy to keep the oil hot.

Energy conservation becomes more and more important as energy costs rise. A great deal of energy is used to cool buildings in summer and heat buildings in winter. Less energy will be needed if buildings are well insulated and energy is not wasted.
Please login or register to read the rest of this content.

Cooling and heating are opposite processes. Cooling is the removal of heat energy from an object or space and heating is the addition of heat energy to an object or space. We use these opposite processes a great deal in our daily lives. For example, in the kitchen we use the cooling provided by a refrigerator to keep food cold. We also use the heat from a stove to cook food.

Nearly 75 percent of the energy used by the average family household in the United States goes for cooling and heating purposes. Air conditioning and refrigeration are the major cooling requirements of a home, while water and space heating are the most important heating requirements.

In the experiments that follow you will learn more about cooling and heating. You will also learn alternative ways of cooling and heating, using such unusual materials as gases, salts, water, and trees.
Please login or register to read the rest of this content.

Having shade trees around a house can decrease the cost of cooling the house with air conditioning. A house not shaded from the sun absorbs some of the light from the sun and heats up the outside surface of the house. If the house is poorly insulated, some of this heat will penetrate into the house, heating up the inside. The air conditioner will use more energy to remove this added heat.

Properly designed roof overhangs can significantly decrease the heating and cooling costs of a house. Because the earth’s axis is tilted, the sun is lower in the winter in the northern hemisphere. In the summer, the sun is higher in the sky. A properly designed roof overhang allows sunlight in the winter to shine through windows and warm the furnishings in the rooms that receive the direct sunlight. This reduces the heating cost in the winter. In the summer, the overhang blocks the sunlight from shining into the window and heating the furnishings. This reduces the cooling cost in the summer.
Please login or register to read the rest of this content.

The evaporation of water for cooling purposes is called evaporative cooling. An important example of this type of cooling is the removal of body heat by humans through sweating. When your body needs to cool, perspiration is released to the surface of your skin where it evaporates. The evaporation of the water in the perspiration causes your skin to cool.

Breezes feel particularly cooling when you have perspiration on your skin. This is because the increased movement of air over your body evaporates more water from your skin than still air does. Water on your skin evaporates more slowly when the humidity is high. This is because the humid air already contains much water vapor. Humid air absorbs less water as vapor than dry air.

Electrical power plants that burn fossil fuels or use nuclear energy to generate electricity use huge water cooling towers for cooling purposes. The water to be cooled is pumped to the top of the tower and allowed to drip down through the tower. As the water moves down the tower, air from the bottom of the tower moves up through the tower, evaporating some of the falling water. The heat lost by the evaporating water cools the remaining water that is collected in a basin under the tower. One pound of water that evaporates in a tower can lower the temperature of 100 pounds (45 kilograms) of other water by nearly 50°C (100°F).
Please login or register to read the rest of this content.

In a typical air conditioning or refrigeration system, a liquid at high pressure is allowed to pass through a valve from a higher pressure to a lower pressure. As the liquid enters the lower pressure region, it changes from a liquid to a gas. This change causes a cooling effect. The liquid cools as it changes to a gas.

In a cooling system, such as a refrigerator or air conditioner, this cold gas is used to cool a box (refrigerator) or a room (air conditioner). Then the cool gas is forced through a compressor pump where it undergoes a warming effect and changes back to a liquid. This excess heat is removed before the liquid is expanded to a gas again. In an air conditioner, the excess heat is blown outside.

Special molecules containing chlorine, fluorine, and carbon atoms are used in most cooling systems. These Freon or chlorofluorocarbon (CFC) molecules are used because they are stable, nontoxic, and will not burn.

In recent years, scientists have discovered that these Freon or CFC molecules are damaging the earth’s ozone layer. Ozone molecules in the upper atmosphere block harmful ultraviolet radiation from reaching the earth. Because these CFC molecules are so stable they tend to stay in the atmosphere for many years, during which time they gradually spread to the upper atmosphere.

In the upper atmosphere, CFC molecules can release chlorine atoms. These atoms cause a chemical reaction that breaks apart ozone. One chlorofluorocarbon molecule may destroy thousands of ozone molecules. Scientists and engineers are looking for new methods of cooling and new gases that are less damaging to the ozone layer.

The main energy used in operating a cooling system is the energy required to run a compressor to force a gas to a higher pressure, where it will change back to a liquid. This energy is normally supplied by electricity or by burning natural gas to run a compressor pump. However, there are systems in which solar energy is used to supply the energy needed for cooling.
